High saturation current.
Small volume, high rated current, low magnetic loss, low ESR, small parasitic capacitance.
Low power loss, suitable for applications of wide temperature and frequency range.
Lead free product, RoHS compliant.
Operating temperature:-40℃～125℃(Including coil's temperature rise)
Customer's specifications are welcome
| Part No. | Inductance(µH) | DCR(mΩ) | Saturation current(A) | Temperature rise current(A) | ||
| ±20% | Typical | Max | Typical | Typical | ||
| YEER1470-2R5M | 2.50 | 2.40 | 3.00 | 16.0 | 19.0 | |
| YEER1470-3R3M | 3.30 | 2.60 | 3.10 | 12.0 | 18.0 | |
| YEER1470-4R7M | 4.70 | 3.00 | 3.50 | 8.2 | 16.0 | |
