High current common mode choke.
High permeability nanocrystalline core.
It's great for suppressing common mode noise.
Flammability corresponding to UL94 V-0.
Operating temperature:-40℃～125℃(Including coil's temperature rise)
| Part No. | Inductance(mH) | DCR(mΩ) | Rated Current (A) | ||
| Min | Typical | Max | Max | ||
| TCB252010S-103 | 10 | 11.5 | 15.0 | 15.0 | |
