TCB60405‑104V nanocrystalline common mode choke with 4.5A rated current. Pin‑to‑pin direct drop‑in replacement for VAC T60405‑R6131‑X204. RoHS compliant, UL94V‑0 flammability, operating temperature ‑40℃ ~ +125℃. Not authorized for safety‑related applications.
TCB60405‑104V is a high‑performance nanocrystalline common mode choke developed as pin‑to‑pin, direct drop‑in replacement for VAC T60405‑R6131‑X204. Adopting high‑permeability nanocrystalline core material, this common mode choke features 4.5A rated current, UL94V‑0 flame retardant rating and wide operating temperature range from ‑40℃ to +125℃. It is RoHS compliant and delivers excellent common‑mode noise suppression performance for power filter applications. This product is not authorized for use in any application related to safety.
<strong>Overview</strong> TCB60405‑104V is a high‑performance nanocrystalline common mode choke, specially developed for direct drop‑in, pin‑to‑pin replacement of VAC T60405‑R6131‑X204. It adopts high‑permeability nanocrystalline core with 4.5A rated current. It meets UL94V‑0 flammability standard and RoHS compliance. Operating temperature ranges from ‑40℃ to +125℃, delivering excellent common‑mode noise suppression performance for power filter applications. <strong>Key Features</strong> • Direct drop‑in & pin‑to‑pin compatible replacement for VAC T60405‑R6131‑X204 • Rated Current: 4.5A • High‑permeability nanocrystalline core material • UL94V‑0 flammability rating • RoHS compliant • Wide operating temperature: ‑40℃ ~ +125℃ <strong>Main Electrical Specifications</strong> Inductance: 10.8mH @10kHz, 2.5mH @100kHz Impedance: 720Ω @10kHz, 2320Ω @100kHz 尺寸图.png 原理图.png 曲线1.png 曲线2.png <strong>Download Datasheet</strong> <a href="此处替换成你上传后的PDF完整URL" target="_blank">Download TCB60405‑104V Datasheet PDF</a> <strong>Notice</strong> This product is not authorized for use in any application related to safety. Specification subject to change without notice. Please check our website for latest information.
Standard common mode choke part. Custom modifications are available, such as part marking, inductance adjustment. New tooling required for major dimensional changes. Contact us for your custom requirements.
